Hose Test Bench
T3000
Mainly used for testing the performance of hydraulic hose assembly after crimped, to test the Max. working pressure and Min. Burst pressure of hydraulic hose. In today's safety conscious environment, hose testing is the final critical step in assuring that the product being delivered to your customer will meet all of the hose and fitting manufacturer's specifications. Testing Pressure up to 3000 Bar / 300Mpa / 43500psi.
Key Advantages:
1.Easy Operating 2.Safety 3.Shock-proof testing window
Technical Specification:
|
Testing Capacity |
For 1/4 Inch～2 Inch Hydraulic Hose |
|
Test Pressure |
Up to 3000bar / 300Mpa / 43500psi |
|
Testing Liquid |
Water / Emulsified Liquid |
|
Safety Shield |
Included |
|
Water tank |
85L |
|
Driving Mode |
Air Drive |
|
Air Supply |
6～8 bar |
|
High Pressure Outlet |
BSP1/4 Female |
|
Zero-Pressure Flow |
18L/min |
|
Weight |
280 kg |
|
L × W × H |
2000 × 800 × 1200mm |
